Cooling And Heating Systems In Surface Treatment Stainless Steel Plate Heat Exchanger Leak Protection
| TYPE |
B(mm) |
C(mm) |
D(mm) |
E(mm) |
THICKNESS(mm) |
WEIGHT(Kg) |
MAX FLOW m3/h) |
DESIGN PRESSURE (Mpa) |
| BT350BR |
318 |
160 |
1060 |
912 |
44+2.23N |
79.3+1.31N(N<132)
82.23+1.404N(N≥132)
|
50 |
0.5 |
|
|
|
Concentrated Heating
District Heating from Waste Heat in Thermal Power Plants
Heating Domestic Hot Water with Waste Heat
Boiler Area Heating
Main Application Area :
Residential heating areas
Mechanical cooling applications
Power plant cooling systems
Cooling systems for piston and turbine operations
Marine and engine cooling and preheating systems
Cooling and heat recovery systems in the sugar industry
Cooling and heat recovery systems in food oil processing
Cooling systems in the chemical industry
Cooling systems in the pharmaceutical industry
Cooling and heating systems in surface treatment
Cooling systems in the paper industry
Cooling and heating systems in the textile industry
Cooling systems in the steel industry
Cooling systems in the automotive industry
Feature :
1, Leak Protection
The safety technology of stainless steel plate heat exchanger is a double-wall plate system designed to allow the detection of any leaks, whether on the outside of the heat exchanger. This safety measure ensures that faulty components can be quickly identified and repaired. As all leaks are external and not internal, the media is always kept separated. This makes the double-wall sanitary plate heat exchanger an ideal solution when working with media that should not be contaminated at any cost.
2,Multi-stage design
Our sanitary plate heat exchanger can also be implemented as a multi-stage solution, where multiple heat exchangers are combined into a single installation, separated by intermediate partitions.
3,High standard and easy maintenance
Our heat exchanger solution complies with stringent industry hygiene requirements and adheres to FDA material standards. The plate pressing process ensures high product quality. We ensure the implementation of flow control, temperature configuration, and appropriate residence time for all media during the processing. The design facilitates quick and trouble-free inspection, maintenance, or cleaning, including Clean-in-Place (CIP), with the convenience of a stainless steel or full stainless steel frame.
4,Save energy
Stainless steel plate heat exchangers can significantly reduce energy consumption and recover up to 95% of energy
